NSK 6305NR
-
Optional specifications
- LINA: 6305NR
- STAN: -
- ORDER: 6305NR
- SD: 25mm
- D: 62mm
- B: 17mm
- R: 1.1 mm
- CR1: 20600[N]
- COR1: 11200[N]
- CR2: 2100[kgf]
- COR2: 1150[kgf]
- FO: 13.2
- A: 3.28 mm
- BB: 1.90 mm
- DD1: 59.61 mm
- RO: 0.60 mm
- RN: 0.5 mm
- DD2: 67.7 mm
- F: 1.70 mm
- DAM1: 31.5 mm
- DA1: 36.0 mm
- DA2: 55.5 mm
- RA: 1.0 mm
- DX: 68.5 mm
- CY: 4.6 mm
- MASS: 0.235[kg]
