Promote INA ZKLN100160-2Z-XL
-
Optional specifications
- 您当前的产品型号: 您当前的产品型号
- 密封: 2Z 两侧最小间隙式密封
- 公差等级: Standard Standard
- 主要尺寸和性能数据:
- d: 100mm
- 0: mm
- -0.008: mm
- D: 160mm
- 0: mm
- -0.015: mm
- B: 55mm
- 0: mm
- -0.25: mm
- Ca: 154,000 N
- C0a: 435,000 N
- Cua: 23,000 N
- nG: Grease 3,300 r/min
- ne: 2,150 r/min
- MR: 2.6 Nm
- ≈m: 4.9 kg
- 尺寸:
- d1: 132 mm
- rmin: 0.6 mm
- r1: min 0.6 mm
- α: 60 °
- 安装尺寸:
- Da: max 150 mm
- da: min 128 mm
- 附加信息:
- caL: 1,900 N/µm
- ckL: 5,800 Nm/mrad
- Mm: 85.3 kg * cm²
- 3: µm
- ZMA100/140:
- AM100:
- MA: 250 Nm
- 25,624: N
- 温度范围:
- Tmin: -30°C
- Tmax: 120°C
ZKLN100160-2Z-XL
